Philips ECG159 - PNP Silicon Replacement Transistor, TO-92
Condition
Unused, new old stock in original package. The photo shows a representative unit from our stock. Same or next business day shipping from our Idaho warehouse. Honest pricing, no nonsense. Online since 1999. We are here for our customers, with a no-hassle satisfaction guarantee.
Product Overview
ECG was Sylvania's replacement line, taken into North American Philips and sold as Philips ECG, so an ECG number is a service cross-reference rather than a JEDEC type. The piece photographed here is a black TO-92 marked ECG above 159 with its three leads still held in a tan kraft paper tape strip, resting on its own bag; the bag label reads ECG 159, PNP-SI, AF PRE AMP, DRIVER SW, COMPL TO ECG 123AP, CASE TO 92, with an E B C pinout sketch, a barcode, and THAILAND, 0H and AG along the bottom, under a yellow ECG COMPONENT header and above a footer naming Philips ECG of Greeneville, TN 37743, Philips Electronics North America Corporation, printed in U.S.A. 9 of these are on the shelf.
Key Features
- Type: PNP silicon AF preamplifier and driver switch, per the bag label; the earlier title on this page said NPN and the label corrects it
- Collector-base voltage: 80 V (VCBO, printed on the bag label)
- Collector-emitter voltage: 80 V (VCEO, printed on the bag label)
- Emitter-base voltage: 5 V (VEBO, printed on the bag label)
- Collector current: 1 A (IC, printed on the bag label)
- Power dissipation: 0.600 W (PD, printed on the bag label)
- Transition frequency: the bag label prints FT 200MHZ; published NTE-lineage data gives that 200 MHz figure as a minimum
- Current gain: about 180 typical, per published NTE-lineage data; the HFE line on this particular bag sits under glare in the photos
- Package and pinout: TO-92 case, E B C left to right per the diagram on the bag label
- Complement: ECG 123AP, per the bag label
- Published cross-reference covers 2N4122, 2N4058, BC158A and BC159, and 2SA500-class types
- Verify against NTE's published ECG159 data before designing in.
Applications
- Service replacement in PNP driver and switch positions
- AF preamplifier stages
- Complementary output pairs alongside an NPN of the 123AP class
- Through-hole board repair calling out a TO-92 PNP
Frequently Asked Questions
How many should I order?
Order the count the repair needs. 9 of this number are on the shelf, each in its own printed ECG bag, so a repair and its spares fit in one order. Shipping is $8 flat rate and free on orders over $28, so small parts like this ship smartest as part of a larger order.
The old title said NPN. Which is it?
PNP. The bag label in the photos reads PNP-SI on its first specification line, and published NTE-lineage data for ECG159 agrees; the same label lists it as the complement to the ECG 123AP, which is the NPN half of that pair. The NPN in the old title was a lister's slip, and this page follows the label. Pinout on that label is E B C, left to right, and on the piece we photographed the leads are still in the kraft paper tape they were packed in.
Nine of them, the one we photographed still taped in the kraft paper strip it was packed in, with the whole datasheet printed on the bag.
