This page covers the parts that set the tempo in a circuit: two-lead quartz crystal resonators, crystal clock oscillators, programmable oscillators and PLL clock buffers. You will find through-hole metal-can crystals in HC-49/U, HC-49/S and HC-18 holders, SMD crystals, full-size and half-size DIP clock oscillators with TTL outputs, and zero-delay and fanout clock buffer ICs.
A crystal and an oscillator are not interchangeable. A crystal is a passive resonator that needs the oscillator circuit on your board; a clock oscillator is a complete module with power, ground and a clock output. Match the frequency to the last printed digit, then the holder or package. For a crystal, also match the load capacitance and whether it runs in fundamental or overtone mode. For an oscillator, match the output type and supply voltage.
Makers include Motorola, Cypress Semiconductor, Epson, Kyocera, Valpey-Fisher, NEL and Jim-Pak.
Related: all integrated circuits and Logic ICs.
