Product Overview
Tin-Plated Copper Long Barrel Terminal for 125 Navy and Industrial Power Distribution
Condition
Unused new old stock (NOS) in clean condition. Straight barrel with sharp knurled markings and intact electro-tin plating throughout.
Ships same or next business day from our Idaho warehouse. Honest pricing, no nonsense.
Online since 1999. We are here for our customers, with a no-hassle satisfaction guarantee.
Product Overview
Burndy YA26-2N is a heavy-duty electrolytic copper compression terminal engineered for 2/0 AWG stranded conductor (125 Navy). Fitted with a seamless long barrel and a two-hole pad drilled for 1/2-inch studs on standard 1-3/4 inch NEMA center-to-center spacing, this terminal delivers robust mechanical pullout resistance and low electrical resistance in critical power feeds.
Key Features
- Electro-tin plated electrolytic copper construction resists oxidation and corrosion
- Sized for 2/0 AWG stranded copper wire (125 Navy)
- Two-hole pad drilled for 1/2-inch diameter mounting hardware
- Standard 1-3/4 inch center-to-center NEMA hole spacing prevents terminal twisting
- Long straight barrel provides deep conductor insertion and maximum crimp contact
- Barrel knurled with color code black and die index 13 for tool verification
- Rated for 600 volts to 35 kV at operating temperatures up to 90°C
Applications
- Terminating feeder runs inside industrial switchgear, motor control centers, and distribution panels
- Bolting heavy battery bank cables and high-output inverter connections in off-grid power builds
- Securing equipment ground leads and bonding jumpers to structural steel or ground bus bars
Frequently Asked Questions
What crimp die is required for this terminal?
The barrel is knurled and stamped for a black die with index 13.
What is the hole pattern on the pad?
The terminal features two holes sized for 1/2-inch studs spaced 1-3/4 inches apart center-to-center to match standard NEMA bus drilling.
Can this lug be used with aluminum cable?
This terminal is stamped and listed for stranded copper conductor only.
Why buy individual lugs here instead of a full carton?
Ordering individually gives you the precise quantity needed for a specific panel or battery setup without paying for excess box quantities. If you are outfitting a full bank, more pieces cost less each, and the price-break table on this page shows what each quantity costs. Orders ship for an $8 flat rate, qualify for free shipping at $28, and ship same or next business day from our Idaho warehouse.
Solid copper and clean tin give high-current wiring the final connection it deserves. Crimp it down, torque the bolts, and never think about that joint again.
