Murrelektronik 4-Pin A-Coded Field-Wireable Right-Angle Sensor Connector
Condition
New old stock (NOS), unused and uninstalled. Physical inspection confirms intact terminal hardware, clean knurled metal coupling threads, and fresh green O-ring seal.
Same or next business day shipping from our Idaho warehouse. Reliable parts since 1999. Honest pricing, no nonsense.
We are here for our customers, with a no-hassle satisfaction guarantee.
Product Overview
Murrelektronik 7000-12561-0000000 is an A-coded, 4-pole M12 male field-wireable connector built with a 90-degree right-angle profile. It utilizes insulation displacement connection (IDC / HARAX) technology for fast conductor termination without requiring soldering or crimping tools.
Key Features
- Connector style: M12 male, 90-degree right angle
- Pin count and coding: 4-pole, A-coded
- Termination method: Insulation displacement connection (IDC / HARAX)
- Wire gauge range: 0.25 mm² to 0.5 mm² (24 to 20 AWG)
- Cable outer diameter: 4.0 mm to 5.1 mm with wire core insulation 1.2 mm to 1.6 mm
- Electrical ratings: Maximum 32 V AC/DC, 4 A current rating
- Environmental protection: IP67 ingress rating when properly mated and tightened
Applications
- Terminating M12 sensor and actuator leads in tight machinery enclosures where straight connectors cannot clear access panels.
- Field-wiring proximity switches, photoeyes, and I/O distribution blocks without dragging soldering stations or crimp tools into the field.
- Custom automation harnesses, CNC retrofit cabling, and bench-top robotics projects requiring secure industrial connections.
Frequently Asked Questions
Do I need special crimp or soldering tools to assemble this connector?
No special crimping or soldering tools are required. The connector uses insulation displacement connection (IDC / HARAX) terminals that pierce the individual conductor insulation and seat the wires as the outer shell components are threaded together.
What cable outer diameter does this connector support?
It is designed for multi-conductor cables with an outer jacket diameter between 4.0 mm and 5.1 mm, with individual wire insulation diameters between 1.2 mm and 1.6 mm.
Why buy an individual field-wireable M12 connector here rather than an entire bulk pack?
Factory distributors often require minimum order quantities or multi-unit pack sizes when all a machine needs is a single right-angle plug to get back in service. We offer this exact connector individually so you can resolve your wiring run without buying excess surplus stock. Shipping is an $8 flat rate, free once your order passes $28, and orders leave our Idaho warehouse the same or next business day.
Right-angle fittings exist because real machines never give you the straight clearance the CAD drawing promised. Thread it on, cinch the housing, and route your sensor cable right where it needs to go.
