Murrelektronik M12 Male Straight A-Coded IDC Connector - 4-Pin, IP67, 32V/4A, Tool-Free Field Termination
Condition
Single unit available. Unused NOS - factory-sealed in original bag. The bag itself shows creasing from storage, but the connector inside is clean and undamaged. Sourced from an electronics distributor that was consolidating inventory. No accessories included beyond the connector itself.
Ships same business day from Idaho. Packed carefully.
Backed by our guarantee. Serving customers since 1999.
Product Overview
Murrelektronik 7000-12481-0000000 is a 4-pin male M12 circular connector in straight (0-degree) orientation, terminating via Insulation Displacement Connection (IDC). A-coded for sensor and actuator use. IDC technology allows tool-free field assembly - no wire stripping required, cutting termination time significantly compared to screw-terminal methods. Rated IP67 when mated and fully tightened. UL listed. Made in Germany. Photos show the actual unit being sold, including the factory-sealed bag with visible part number and ratings label.
Key Features
- M12 circular connector - 4-pin, male, straight (axial) orientation
- A-coded - standard coding for sensor and actuator signal connections
- IDC (Insulation Displacement Connection) termination - no wire stripping, no tools required
- Cable diameter range: 4 to 5.1mm
- Wire cross-section: 0.25 to 0.5mm² (20 to 24 AWG)
- Max. 32V AC/DC operating voltage
- Max. 4A per contact
- IP67 rated when mated and tightened
- Operating temperature: -25°C to +85°C
- UL listed - confirmed on packaging label
- Made in Germany
Applications
- Sensor and actuator connections on automated production and assembly lines
- PLC and distributed I/O signal wiring in factory automation systems
- Robotics cable termination where field-reworkable connections are required
- Packaging, material handling, and conveyor system instrumentation
- Custom cable builds for prototyping or lab setups using M12 A-coded devices
Frequently Asked Questions
What female connector or receptacle does this mate with?
Any standard M12 female A-coded receptacle or cable socket with a 4-pin configuration. Confirm A-coding and pin count on your existing receptacle before ordering. B-coded, D-coded, and other M12 coding types are not compatible.
What cable will this accept?
Cables with an outer diameter of 4 to 5.1mm and conductors in the 0.25 to 0.5mm² range (20 to 24 AWG). Cables outside these ranges may not seat reliably or could damage the IDC contacts.
Does it come with installation instructions?
Not included. Murrelektronik publishes installation documentation through their website and product datasheets.
Is the IP67 rating active out of the box?
IP67 is achieved only when the connector is fully mated and the coupling nut is tightened to the specified torque. The connector alone is not sealed. Follow the manufacturer's torque specification and use proper cable strain relief to maintain the rating in service.
Is this compatible with DeviceNet or CANopen systems?
A-coded M12 connectors are the standard physical interface for DeviceNet and CANopen. This connector is A-coded and 4-pin, which matches that wiring scheme physically. Protocol compatibility depends on the devices and cabling in your system - confirm your network wiring requirements before installing.
IDC has been around long enough that experienced wiring techs have strong opinions about it - most of them positive once they've done a hundred field terminations the old way. This one is still sealed from the factory, waiting for the installation that needs it.
