TEPRO TM Black Aluminum Chassis-Mount Wirewound Resistor - 2 Ohm, 5 W
Condition
Unused, New Old Stock. The photo shows a representative unit from our stock.
Same or next business day shipping from our Idaho warehouse. Honest pricing, no nonsense.
Online since 1999. We are here for our customers, with a no-hassle satisfaction guarantee.
Product Overview
The TM line is Tepro's aluminum housed, chassis-mount precision power wirewound family, an anodized housing over a steatite or alumina core with an epoxy-protected winding and a high-temperature silicone seal, per Tepro's published TM series data. The unit photographed is a black housing with a ribbed top face, stamped in black on black, TEPRO over TM 5W on the top and 2 Ohm 0.1% along the ribbed flank, which takes raking light to read at all. Two mounting ears sit diagonally opposite each other with one bolt hole each, and a flat strap with a pierce hole comes out of each end. One frame lays the part on a light crinkled surface beside a yellow handwritten sticky note reading TEPRO, TM, 5W, 2 Ohm, 0.1%, and the note takes up considerably more of the frame than the resistor does. Three are on the shelf at this value, sold one at a time.
Key Features
- Housing of the unit photographed stamped TEPRO TM 5W on the top face and 2 Ohm 0.1% on the flank, giving 2 ohm at 0.1% tolerance
- Tepro's published TM data rates the TM 5 at 7.5 W on Tepro's own basis and 5 W on the MIL basis, covering 0.005 to 20K ohm; the housing here carries the 5W marking
- TM standard tolerances run +/-0.1% to 5%, with closer tolerances to 0.01% available, so the stamped 0.1% sits at the tight end of the published standard range (Tepro published TM data)
- Temperature coefficient +/-50 ppm across the 1 to 9.9 ohm band, where 2 ohm sits (Tepro published TM data)
- Published rating basis: full power at 25 degC mounted on a proper heat sink, 275 degC maximum hotspot, 1% maximum delta-R over 1000 h load life (Tepro published TM data)
- Dielectric strength 1000 VAC on TM-5, TM-10 and TM-25, insulation resistance 10000 Mohm minimum, environmental test basis MIL-R-18546 (Tepro published TM data)
- Tinned copper flattened-and-pierced terminals are the published style on TM-5 through TM-50, with threaded terminals reserved for TM-100 and TM-250 (Tepro published TM data)
- Verify against Tepro's published TM series data before designing in.
Applications
- Shunt and current sense legs in power supplies and motor drives
- Snubber and damping networks in power stages
- Load and dummy load positions in test setups
- Panel or heatsink mounted spots in industrial control gear
Frequently Asked Questions
How many should I order?
Order the count the build needs. Three of this value are on the shelf, sold one at a time rather than in fixed packs, so a sense leg and a spare come out of a single order. Shipping is $8 flat rate and free on orders over $28, so small parts like this ship smartest as part of a larger order.
Does it have to be bolted to a heat sink?
Tepro's published TM data rates the part at full power at 25 degC with the housing mounted on a proper heat sink, and names a 6 x 4 x 2 x .040 in aluminum chassis as the recommended sink for the TM-5 and TM-10 sizes, with no derating needed out to 75 degC ambient. The two ears on the unit photographed each carry a single bolt hole and no hardware is in the photos, so the screws are yours to supply.
