Product Overview
Analog Devices OP482 Quad JFET-Input High Speed Operational Amplifier
Condition
Used equipment pull. Visual inspection confirms intact 14-pin through-hole package and legible surface markings: T9621, OP482G, and M18084 0. Function testing not performed.
Same or next business day shipping from our Idaho warehouse. Reliable parts since 1999. Honest pricing, no nonsense.
We are here for our customers, with a no-hassle satisfaction guarantee.
Product Overview
The Analog Devices OP482G is a quad low-power, high-speed operational amplifier featuring JFET inputs. Designed for applications requiring high input impedance and low input bias currents combined with fast settling and high slew rates, each amplifier draws a maximum of 250 µA while providing a 4 MHz gain bandwidth product.
Key Features
- Four independent JFET-input operational amplifiers in a single package
- 4 MHz typical gain bandwidth product with a 9 V/µs slew rate
- Low supply current of 250 µA maximum per amplifier
- Wide operating supply range from ±4.5 V to ±18 V or 9 V to 36 V single supply
- Standard 14-pin through-hole dual in-line package (DIP-14)
- -40°C to +85°C operating temperature rating
Applications
- Bench instrumentation and sensor signal conditioning circuits requiring high input impedance.
- Active filter stages and audio preamplifiers where low current draw and fast slew rates are needed.
- Maker and DIY synthesizer builds needing reliable quad JFET op amps for CV buffers and audio routing.
Frequently Asked Questions
What package type is this integrated circuit?
This is a standard 14-pin plastic dual in-line package (DIP-14) for through-hole PCB mounting or socket insertion.
What are the marked codes on the top of the chip?
The visible surface markings are T9621, OP482G, and M18084 0 alongside the Analog Devices logo.
Why buy this specific pulled IC rather than an unverified multi-pack?
You receive the exact photographed Analog Devices component with verified markings rather than sorting through unvetted bulk lots. Orders ship for an $8 flat rate, qualify for free shipping at $28, and ship same or next business day from our Idaho warehouse.
Quad JFET speed in a classic 14-pin DIP footprint makes this an easy drop-in fix for precision analog repairs and breadboard prototypes alike.
