Square D 9001JT1-L29 Blue Push-to-Test Pilot Light
Condition
This Square D 9001JT1-L29 push-to-test pilot light is New, unused stock, and it is stock of one. The photographed sample was taken out of its original Square D box for these photos; the box and its factory instruction sheet are shown alongside the light for reference. The label, lens, and terminal block all photograph clean with no marks from installation or wiring.
Same or next business day shipping from our Idaho warehouse. Honest pricing, no nonsense.
Online since 1999. We are here for our customers, with a no-hassle satisfaction guarantee.
Product Overview
The Square D 9001JT1-L29 is a compact push-to-test pilot light from the 9001J Series B line, built for panel and enclosure indicator duty. It carries a blue lens and mounts through an 11/16 inch (0.69 inch) panel hole, sealed with the gasket and locking nut shown in the photos. Line input is 110/120VAC at 50/60Hz; internally the unit steps that down through a transformer to drive a low-voltage replacement lamp, type 755 or 6MB. Wiring runs to three screw terminals on the back of the housing, corresponding to L1, L2, and C on the wiring diagram printed on the unit's own label, sized for 14 AWG wire. The lens body is plastic, and the unit carries UL Listing (Ind. Cont. Eq. 572A) and CSA approval, with a NEMA 4/13 rated enclosure. Made in the USA.
Key Features
- Blue lens, push-to-test type - press the lens to test the lamp without removing it
- 110/120V 50/60Hz transformer lamp input; replacement lamp type 755 or 6MB
- Series B, UL Listed (Ind. Cont. Eq. 572A) and CSA approved
- NEMA 4/13 rated enclosure
- 11/16 inch (0.69 inch) mounting hole; three screw terminals (L1, L2, C per the label diagram) sized for 14 AWG wire
- Plastic lens material, Made in USA
Applications
- Panel builders adding a blue run or status indicator to a control panel door
- Maintenance techs replacing a failed or missing pilot light on Square D 9001J series equipment
- OEM machine builders needing a push-to-test light to verify a lamp without opening the panel
- Electricians stocking a NEMA-rated indicator light for a wet or washdown location
Frequently Asked Questions
What lamp does the 9001JT1-L29 use?
It takes replacement lamp type 755 or 6MB, per the label on the unit. Line input is 110/120VAC, but an internal transformer steps that down to drive the low-voltage lamp, so no separate transformer is needed to run it.
What size hole does it mount in?
The bushing is sized for an 11/16 inch (0.69 inch) panel cutout, with the gasket, washer, and locking nut shown in the photos handling the panel seal.
How do I wire it?
Three screw terminals on the back correspond to L1, L2, and C on the wiring diagram printed on the unit's own label, and are sized for 14 AWG wire.
Is this a full replacement unit or just a lens?
It is the complete pilot light assembly: lens, transformer body, mounting bushing, gasket, and nut, ready to wire into your panel. Not confirmed - verify the lamp is included before use, since the label calls out lamp type 755 or 6MB as the correct replacement.
Why buy this one instead of a used pull or an unsorted lot?
This is a single, New 9001JT1-L29, photographed and confirmed rather than an unknown quantity from a used lot or grab-bag assortment. Shipping is a flat $8, free once your order passes $28, and it leaves our Idaho warehouse the same or next business day.
A blue pilot light spends most of its life just sitting there, doing its job by not needing attention - until the day you push the lens and it tells you, right then, whether the lamp or the circuit behind it is still good. Wire this one in and let it stand its post on your panel.
