Product Overview
Doric 500 Series Model D Panel Indicator, Clean and Complete with Its Manual
Condition
Used, in excellent cosmetic condition with very little sign of use. The front panel, red display window, and channel selector knob are clean and intact, and the rear terminal strip is complete, with two factory jumper wires in place at the OUT terminals. The rear label is fully legible: Model D and 230 VAC boxes checked, Multi-Selector option checked, serial number 02080295, with a FOR CURRENT ONLY sticker above the label and a degrees C unit label on the front bezel. One brass panel mounting strap is fitted; mounting hardware may be incomplete. The unit is untested because we lack a compatible setup. Includes the operator's manual.
Same or next business day shipping from our Idaho warehouse. Honest pricing, no nonsense.
Online since 1999. We are here for our customers, with a no-hassle satisfaction guarantee.
Product Overview
The VAS Engineering Doric 500 Series Model D is a general-purpose digital panel indicator built for front-panel mounting in OEM systems, test setups, and process monitoring stations. This unit carries the Multi-Selector option: a 6-position channel knob on the front panel that matches the rear screw terminal strip labeled IN1 through IN6 plus OUT, so one display can be switched across six inputs. Per the factory label it is the 230 VAC version, and the FOR CURRENT ONLY sticker marks its configured input, consistent with the Model D wiring diagram for mA DC signals printed on the label. The degrees C bezel label suggests its previous service displayed temperature from that current signal. Input range and calibration are set at the factory on this series, so verify this unit's configuration against the included operator's manual and your application before installation.
Key Features
- Model: Doric 500 Series, Model D, serial number 02080295
- Display: red digital front-panel readout
- Input: current input per the factory FOR CURRENT ONLY sticker - verify range before use
- Multi-Selector option: 6-position channel knob with rear terminals IN1 through IN6 plus OUT
- Power: 230 VAC per the checked box on the factory label
- Mounting: front-panel installation, one brass mounting strap fitted
- Made in USA by VAS Engineering Instruments Division, San Diego
- Included: indicator and operator's manual
Applications
- Process engineer filling an empty panel cutout on a monitoring station
- Lab technician adding a switchable six-channel readout to an instrumentation rack
- OEM rebuilder replacing a failed indicator in a legacy system built around the Doric 500 series
- Collector of vintage test gear who wants the matching-era display, with the manual to make sense of it
Frequently Asked Questions
Has it been tested?
No. We do not have a compatible setup to exercise it. Cosmetically it shows very little use and appears clean and complete, and it is backed by our no-hassle satisfaction guarantee.
What is included?
The Doric 500 Series Model D indicator and its operator's manual, exactly as shown in the photos. One mounting strap is on the unit; other mounting hardware may be incomplete.
What input signals does it accept?
The factory sticker reads FOR CURRENT ONLY, and the label's Model D wiring diagram covers mA DC input. The exact range and calibration are factory set and not confirmed, so verify against the manual and your signal before installation.
What power does it require?
The 230 VAC box is checked on this unit's factory label, so wire it for 230 VAC, not 115 VAC.
Why buy a single unit here instead of hunting bulk lots on eBay or Amazon?
Because you need one indicator, and that is exactly what we sell - no lot, no extras. Shipping is $8 flat rate and free over $28, which this unit clears on its own, so it ships free, same or next business day from Idaho.
One indicator, one manual, one open cutout somewhere waiting for a readout. If your panel has a Doric-sized hole in it, this is the tidy, documented way to fill it.
