4700 pF 50 V X7R Multilayer Ceramic Chip Capacitor, 1206 Thin Body, +/-10 %
Condition
Unused new old stock (NOS). Sold each. The value is not printed on the chip body.
Ships same or next business day from our Idaho warehouse. Honest pricing, no nonsense.
Online since 1999. A no-hassle satisfaction guarantee on every order.
Product Overview
Panasonic's ECU-V line puts 4700 pF (4.7 nF, 0.0047 uF) into the 1206 case under the number ECUV1H472KBM: a multilayer ceramic chip with X7R dielectric, a 50 V DC rating and +/-10 % tolerance, 0.65 mm maximum thickness for low-profile surface mount assembly.
Key Features
- Capacitance: 4700 pF (4.7 nF, 0.0047 uF), value code 472
- Rated voltage: 50 V DC
- Tolerance: +/-10 %
- Dielectric: X7R
- Case: 1206, body 3.2 x 1.6 mm, 0.65 mm maximum thickness
- Construction: multilayer ceramic, surface mount, two end terminations
Applications
- Bypassing a supply pin right beside a logic or op amp IC, next to a larger bulk capacitor
- RC low-pass filters on sensor and signal lines
- Noise filtering where a cable or connector enters a board
- Board repair where the schematic calls for 4700 pF or 4.7 nF in a 1206 position
Frequently Asked Questions
Is a 50 V rating right for a 5 V or 12 V board?
Yes. The rating is 50 V DC, so 3.3 V, 5 V, 12 V and 24 V rails all sit well inside it. A higher rating than the rail is headroom, not a mismatch.
This value is the middle child of the bypass drawer: too small to hold up a rail, about right for shunting high-frequency hash off a supply pin or an input line. Set it as close to the pin it guards as the layout allows.
