A182 316/316L Stainless Reducer 3/4 NPT x 1/2 Socket Weld, Sold Each

316/316L Stainless Reducer, 3/4 in Threaded to 1/2 in Socket Weld

Condition

Unused, new old stock; clean and in excellent condition, never installed or welded. The photos show bright machined surfaces with the fine turning lines still on the body and clean threads with no sealant tape, thread compound, or wrench marks visible in these frames. The socket bore is smooth and shows no weld discoloration, and the brown ink marking reads across all three lines, though the start of the 3/4X1/2 line is rubbed thin and a vertical machining line runs down through 3M, 316/316L, and E141584. We stock more than one of these, so the piece in the photos is representative of the group rather than the individual fitting pulled for your order.

Same or next business day shipping from our Idaho warehouse. Honest pricing, no nonsense.

Online since 1999. We are here for our customers, with a no-hassle satisfaction guarantee.

Product Overview

This is a short forged stainless coupling that steps a 3/4 in female pipe thread down to a 1/2 in socket weld end, letting a threaded run hand off to welded pipe inside a single fitting instead of a stack of adapters. The body carries three ink-stamped lines: 3/4X1/2 3M across the top, A182 316/316L in the middle, and UOI E141584 at the bottom. The part does not spell out what that last code stands for, so we quote it as stamped and read no meaning into it. A182 316/316L is the forging grade covering austenitic 316 and its low-carbon 316L variant, the material specified where chlorides, acids, and washdown chemistry would chew through carbon steel and where post-weld carbide precipitation is a concern. Against the metric tape laid alongside it in the photos the body runs roughly 5 cm, a shade under 2 in, end to end. One end shows machined female pipe threads cut right to the face; the other is a smooth counterbored socket with an internal shoulder that seats 1/2 in pipe at the correct depth before the fillet weld goes on outside. The marking does not spell out a 3000 or 6000 pressure class, so that rating is not confirmed here.

Key Features

• Ink stamped on the body: 3/4X1/2 3M, A182 316/316L, UOI E141584
• Material: A182 316/316L austenitic stainless steel, per the stamped grade
• Threaded end: 3/4 in female pipe thread, NPT form; the thread standard itself is not called out in the marking
• Socket end: smooth counterbore sized for 1/2 in pipe, with an internal shoulder
• Overall length approximately 5 cm, just under 2 in, read against the tape in the photos
• Pressure class: not confirmed, no 3000 or 6000 designation is spelled out on the part. Verify against the manufacturer's data before use
• Condition: New, unused, never installed or welded. Sold each

Applications

• A plant maintenance tech stepping a 3/4 in threaded stainless branch down to 1/2 in welded pipe without stacking two more leak paths into the run
• A fab shop welder building a small 316 skid who wants the threaded end at the gauge or valve and the welded end buried in the piping
• A chemical, marine, or coastal installation where 316/316L is specified because chlorides would pit a lesser alloy
• Someone restocking the spares drawer for an existing 316 system and matching the grade already in the line

Frequently Asked Questions

What exactly is stamped on it?

Three ink lines. The first reads 3/4X1/2 3M: the two end sizes, followed by a designation sitting where a forged fitting usually carries its pressure class, though the marking never spells out 3000 or 6000. The second reads A182 316/316L, the ASTM forging grade. The third reads UOI E141584; the part does not say what that code stands for, so we quote it exactly rather than assign it a meaning. All three lines can be made out in the photos, with the start of the first line rubbed thin and a vertical machining line crossing them, so you can read them yourself before you buy.

Which end is threaded and which end is welded?

One end is 3/4 in female pipe thread, machined clean and visible in the photos. The other is a smooth socket bore sized for 1/2 in pipe, with an internal shoulder that stops the pipe short of the bottom so the joint can expand without cracking the weld. Because the two ends are different sizes, this piece reduces and changes joining method in one fitting.

Can you confirm the pressure rating?

No. The stamp gives size and material grade but no spelled-out pressure class, and we do not have the manufacturer's data in hand. Not confirmed, verify the class against the manufacturer's data before putting this in a pressure system. What we can confirm is on the part itself, and it is all in the photos.

Why buy two or three of these here instead of a full box somewhere else?

Because a transition fitting is something you need in ones and twos. One repair takes one. Building both sides of a skid might take three. The supply house answer is usually a minimum box you will still be stepping over in five years, and the count you actually wanted is the only part of it that ever gets used. We stock this one deep enough that you can take the exact number the job calls for and leave the rest on our shelf. Shipping is a flat $8 and goes free once your order clears $28, and orders leave our Idaho warehouse the same or next business day.

Two ways of joining pipe meet inside one short piece of 316: one end you turn with a wrench, the other you burn in with a torch. Put it in your line and the argument between threaded and welded ends right there.
