Product Overview
Square D Class 9007 Series A Turret Head Wobble Stick Position Switch
Condition
Unused new old stock (NOS). Visual inspection confirms intact zinc switch body, straight spring-mounted wire actuator, and clean terminal contacts. Markings legible: Square D Limit Switch Class 9007 Series A, Type C62K, Plug-In Unit Less Head C062, Type 6P, A600 R300, Listed Ind Cont EQ 572A.
Same or next business day shipping from our Idaho warehouse. Reliable parts since 1999. Honest pricing, no nonsense.
We are here for our customers, with a no-hassle satisfaction guarantee.
Product Overview
Square D 9007 C62K combines a Class 9007 Series A turret head with a C062 modular plug-in switch body and a multi-directional spring rod actuator. Built for industrial position detection, the flexible wire extension trips the internal contacts when deflected from any angle, returning to center automatically when released. The die-cast zinc enclosure is rated NEMA Type 6P for submersible service alongside Type 4, 12, and 13 protection against oil, water, and industrial coolants.
Key Features
- Complete turret-head mechanical position switch with C062 plug-in base and C62K head assembly
- Actuator: Multi-directional spring-return wire extension (cat whisker wobble stick)
- Contact arrangement: 2 NO / 2 NC snap-action contacts with same polarity per pole
- Electrical ratings: NEMA A600 AC heavy-duty rating, NEMA R300 DC rating
- Enclosure rating: NEMA Type 1, 2, 4, 6, 6P, 12, and 13 (submersible oil-tight and dust-tight)
- Conduit entrance: Standard 1/2-14 NPT threaded connection
- Rugged die-cast zinc alloy housing
Applications
- Detecting off-track cartons or irregularly oriented parts along conveyor lines without jamming
- End-of-travel sensing and guard monitoring on machine tools exposed to cutting fluids and washdown
- Material handling diverters and sortation gates requiring omnidirectional physical actuation
- Custom automated assembly fixtures and workshop mechanism limits needing durable mechanical triggering
Frequently Asked Questions
Can the turret head be repositioned relative to the conduit entry?
Yes. The turret head on the Square D 9007 series can be mounted in four 90-degree orientations on the plug-in base, allowing the actuator and conduit entrance to align with existing mounting layouts.
How does the multi-directional spring rod actuate the contacts?
The wire extension trips the snap-action switch contacts when pushed in any radial direction from its centerline, then springs back to center when the passing object clears.
What is the relationship between the 9007 C62K catalog number and the C062 marking on the body?
Type C062 designates the plug-in switch receptacle base assembly without an operating head, while 9007 C62K represents the complete factory assembly consisting of the C062 plug-in unit fitted with the spring rod turret head.
A classic wobble switch does not care which angle an off-track part hits it from, as long as it trips the circuit and snaps back for the next one. Mount it on the line and let the hardware take the beating.
