Contrinex LRS-3031-304 Compact 30x30mm Retroreflective Sensor, PNP Dark-ON, M8 Connector, 10-36V DC
Condition
Single unit available. Unused, in original packaging, acquired from a contract manufacturer clearing surplus stock. Evaluation: Visual inspection only. Function testing not performed.
Ships same business day from Idaho. Packed carefully.
No hassle resolution if there is an issue. Serving customers since 1999.
Product Overview
Contrinex LRS-3031-304 is a compact retroreflective photoelectric sensor in a 30x30x15mm square housing. It detects objects by emitting a light beam toward a separate reflector — when an object breaks the beam, the sensor switches output. Output is PNP, Dark-ON, meaning the output activates when the beam is interrupted. Rated IP65, powered at 10-36V DC, and connects via M8 3-pin connector. Maximum sensing range is 2000mm with a compatible reflector. Switching frequency is 500 Hz. Housing is PBTP (Crastin) with a glass optical window.
Key Features
- Output type: PNP, Dark-ON
- Operating voltage: 10-36V DC
- Max sensing range: 2000mm (2 meters) with reflector
- Connection: M8 3-pin connector
- Switching frequency: 500 Hz
- IP rating: IP65
- Housing: 30x30x15mm square body, PBTP (Crastin)
- Optical window: Glass
Applications
- Object presence and absence detection on manufacturing and assembly lines
- Part counting on conveyor systems
- End-of-travel detection in material handling equipment
- Packaging line registration and position sensing
- Replacement or spare for existing Contrinex LRS-3031 series installations
Frequently Asked Questions
Does this sensor include a reflector?
No. A separate reflector is required for retroreflective operation and is not included. Contrinex and third-party reflectors compatible with this sensor family are available independently.
Is this PNP or NPN output?
PNP, Dark-ON. The output activates when the light beam is interrupted. Verify your control system accepts a PNP sourcing output before ordering. The NPN equivalent in this series is the LRS-3031-302.
What connector does this sensor use?
M8 3-pin connector. A compatible M8 cable or pigtail is required and is not included.
What power supply does it require?
10-36V DC. It is not compatible with AC power supplies.
What is the maximum sensing distance?
2000mm (2 meters) under clean conditions with a compatible reflector. Actual range may be reduced by dirt, dust, or misalignment between the sensor and reflector.
