Balluff BES 00P7 M8 Flush Inductive Proximity Switch 10-30VDC
Condition
Used. Evaluation: Visual inspection only. Function testing not performed. Includes two mounting nuts and one lock washer on the threaded barrel. Markings legible: BALLUFF on sensing face, CE mark on barrel collar.
Same or next business day shipping from our Idaho warehouse. Reliable parts since 1999. Honest pricing, no nonsense.
We are here for our customers, with a no-hassle satisfaction guarantee.
Product Overview
Balluff's BES 00P7 (model BES 516-324-G-E5-C-S49) provides non-contact metallic target detection in a compact M8x1 threaded stainless steel barrel. Built for flush mounting with a 2.0 mm sensing distance, this inductive switch delivers a PNP normally open (NO) output across a 10 to 30 VDC supply range. Rated for switching frequencies up to 5000 Hz with an IP68-rated seal and an integrated 3-pin M8 male plug, it handles fast-cycling automated equipment and harsh industrial workcells.
Key Features
- M8 x 1.0 metric threaded barrel in stainless steel with PBT sensing face
- 2.0 mm rated operating distance for flush (shielded) mounting
- PNP normally open (NO) switching output
- 10 to 30 VDC operating supply voltage range
- High-speed switching frequency up to 5000 Hz
- M8 male 3-pin connector termination
- IP68 ingress protection rating for washdown and damp conditions
- Includes two threaded lock nuts and a lock washer
Applications
- Detecting end-of-stroke and home positions on pneumatic slides or automated tooling
- Counting high-speed teeth or cam lobes on machinery rotating up to 5 kHz
- Integrating metal part presence detection into custom CNC router builds or DIY automation fixtures
- Monitoring cylinder or actuator travel in wet, dusty, or coolant-sprayed machine bays
Frequently Asked Questions
What is the pinout for the 3-pin M8 connector?
The standard M8 3-pin configuration for this Balluff DC 3-wire sensor connects pin 1 to positive supply (+10-30 VDC), pin 3 to negative supply (0 VDC), and pin 4 to the PNP switching output.
Is a mating cable or cordset included?
Not included.
What condition is this sensor in, and has it been tested?
This sensor is in used condition with clean barrel threads, intact connector pins, and attached mounting hardware. Evaluation is visual inspection only; function testing has not been performed.
Nothing steadies a high-speed automation line quite like an M8 proximity switch doing its quiet, five-thousand-cycle-a-second job. Thread it into place, cinch the lock nuts, and let your controller know exactly where the metal landed.
