CTS 761-3-R10K 10k Ohm 16-Pin DIP Isolated Resistor Network Used

CTS Series 761 10k Ohm 8-Resistor Isolated DIP-16 Network

Condition

Used equipment pull. Marked CTS8440 and 761-3-R10K on top face with visible pin 1, 8, 9, and 16 index markings. Through-hole pins show solder residue and handling from prior board removal. Evaluation: Visual inspection only. Function testing not performed. Verify suitability before use.

Same or next business day shipping from our Idaho warehouse. Reliable parts since 1999. Honest pricing, no nonsense.

We are here for our customers, with a no-hassle satisfaction guarantee.

Product Overview

CTS Corporation 761-3-R10K thick-film cermet resistor network in a standard 16-pin dual in-line package. The schematic 3 configuration contains 8 isolated, individual 10 kΩ resistors across opposing pin pairs (pins 1-16, 2-15, through 8-9) with no common internal bus.

Key Features

• 8 isolated cermet thick-film resistors
• 10 kΩ resistance per element with ±2% tolerance
• 2.3 W total package power rating
• 100 V maximum operating voltage
• 16-pin through-hole dual in-line package
• Opposing-pin isolated circuit arrangement

Applications

• Pull-up or pull-down arrays on legacy digital logic lines
• Individual line termination on vintage computing and industrial control boards
• Breadboard prototyping and bench repair requiring isolated 10 kΩ resistor groupings

Frequently Asked Questions

What is the internal circuit layout for the 761-3 configuration?

The -3 designation provides 8 completely isolated resistors. Each resistor connects directly between opposing pins (pins 1 to 16, 2 to 15, 3 to 14, 4 to 13, 5 to 12, 6 to 11, 7 to 10, and 8 to 9), with no shared internal tie points.

What do the top markings indicate on this piece?

The top surface is marked CTS8440 and 761-3-R10K with molded pin numbers 1, 8, 9, and 16.

Why buy an individual pull instead of sourcing a full factory lot?

When restoring vintage hardware or repairing an older controller, you often need just a single original-specification component rather than a bulk reel or wholesale lot. Orders ship for an $8 flat rate, ship free once your order total reaches $28, and leave our Idaho warehouse the same or next business day.

Eight isolated 10k paths packed into one ceramic carrier - steady, predictable passive hardware ready to drop into a classic board.
