Product Overview
Mitsubishi M5L2114LP-2 1024 x 4-Bit NMOS Static RAM DIP-18
Condition
Used. Equipment pull. Markings legible: JAPAN 820702 with Mitsubishi logo and part number M5L2114LP-2. Evaluation: Visual inspection only. Function testing not performed. Sold as individual unit.
Same or next business day shipping from our Idaho warehouse. Reliable parts since 1999. Honest pricing, no nonsense.
We are here for our customers, with a no-hassle satisfaction guarantee.
Product Overview
The Mitsubishi M5L2114LP-2 is a 4096-bit static random access memory organized as 1024 words by 4 bits in an 18-pin dual in-line package. Fabricated using NMOS technology, this low-power variant features a 200 ns maximum access time, common three-state data input/output terminals, and single +5V power operation with full TTL compatibility.
Key Features
- 1024 words x 4-bit static RAM organization
- 200 ns access and cycle time (-2 speed grade)
- Low power ("LP") dissipation rating
- Standard DIP-18 package format
- Single +5V power supply requirement (+/-10%)
- Common three-state data inputs and outputs
- Fully TTL compatible inputs and outputs
Applications
- Replacing failed 2114 SRAM chips on vintage arcade game boards, pinball machines, and 8-bit microcomputers
- Restoring classic synthesizer, sequencer, and audio processing hardware
- Breadboarding retro microcomputing projects based on 6502, Z80, or 6800 architectures
Frequently Asked Questions
What is the access time of the M5L2114LP-2?
The -2 suffix designates a 200 ns maximum access and read/write cycle time.
Are testing sockets or accessories included?
Not included. This listing is for the bare integrated circuit only.
Why buy this individual pull over chasing an unverified bulk lot?
Buying an individual, identified IC gives you the exact speed-graded part required for your specific board repair without purchasing excess inventory. Orders ship for a flat $8 rate, ship free once your order total exceeds $28, and leave our Idaho warehouse the same or next business day.
Vintage silicon carries the logic of the systems that built computing. Plug it into the socket, power up the rails, and bring a classic board back to life.
