Fairchild 74LS42PC 4-Line BCD to 10-Line Decimal Decoder DIP-16
Condition
Used equipment pull. Package markings stamped: 74LS42 PC with Fairchild logo, date code 8631, SINGAPORE. Evaluation: Visual inspection only. Function testing not performed.
Same or next business day shipping from our Idaho warehouse. Reliable parts since 1999. Honest pricing, no nonsense.
We are here for our customers, with a no-hassle satisfaction guarantee.
Product Overview
The Fairchild 74LS42PC is a Low-Power Schottky TTL integrated circuit designed for 4-line BCD to 10-line decimal decoding and 1-of-8 demultiplexing. Featuring four binary-coded inputs and ten mutually exclusive active-low outputs, it decodes standard 8-4-2-1 BCD codes for display driving, memory addressing, and digital control circuits.
Key Features
- Low-power Schottky (74LS) TTL technology
- 4 BCD input lines to 10 active-low decimal outputs
- Operates on standard 5.0 V logic supply (4.75 V to 5.25 V operating range)
- Standard 16-pin dual in-line package (DIP-16) for through-hole mounting
- Can function as a 1-of-8 demultiplexer using the D input as an active-low enable line
Applications
- Restoring logic boards, industrial controllers, and vintage computing hardware
- Breadboarding decimal decoding and indicator drive stages in custom electronics
- Routing control lines and address decoding in discrete logic projects
Frequently Asked Questions
Can this chip be used as a 3-line to 8-line decoder?
Yes. Utilizing inputs A, B, and C as address lines while driving input D as an active-low strobe configures the 74LS42 as a 1-of-8 line demultiplexer.
Why buy a single pulled unit instead of a bulk lot?
Purchasing an individual vintage component supplies the specific replacement part needed for a repair without accumulating excess inventory. Flat rate shipping is $8, or free on orders over $28, shipped same or next business day from our Idaho warehouse.
Vintage TTL logic has a straightforward honesty - when a classic build needs a decade decoded, the right 16-pin chip drops in and gets right to work.
Shipping? $8 flat rate, free once your order passes $28 - and it leaves the Idaho warehouse the same or next business day.
