Product Overview
50-Ohm Straight Coaxial Cable Termination Assembly for RF Test and Radio Lines
Condition
Unused new old stock (NOS). Component parts remain sealed in the original printed factory packaging marked with date code 87 48. Includes straight plug body, gold-plated center contact pin, crimp ferrule, and sealing O-ring.
Same or next business day shipping from our Idaho warehouse. Reliable parts since 1999. Honest pricing, no nonsense.
We are here for our customers, with a no-hassle satisfaction guarantee.
Product Overview
The AMP 2-330058-1 is a COAXICON series 50-ohm straight male BNC RF connector kit engineered for terminating small-diameter coaxial lines. Built with silver-plated brass housing, a polypropylene dielectric, and a gold-plated center contact, it provides clean RF continuity up to 2.5 GHz in test gear, bench interconnects, and communications systems.
Key Features
- COAXICON series straight male BNC plug configuration
- 50-ohm characteristic impedance rated for operation up to 2.5 GHz
- Compatible with miniature coaxial lines including RG-174, RG-188, and RG-316
- Bayonet-lock mating mechanism for secure, quick-disconnect retention
- Gold-plated center pin contact for low contact resistance and corrosion resistance
- Silver-plated brass outer body with crimp-style cable ferrule termination
- Sealing O-ring included to prevent moisture ingress at the interface
Applications
- Terminating custom-length test patch leads and oscilloscope scope probes
- Assembling low-loss pigtails for amateur radio, SDR receivers, and bench instrumentation
- Repairing damaged coaxial cable runs inside rack-mounted avionics and industrial telemetry cabinets
- Building prototype RF breadboards and breadboard-to-analyzer interconnect cables
Frequently Asked Questions
Which coaxial cable sizes work with this connector kit?
This kit is sized for miniature 50-ohm flexible coaxial cables, specifically RG-174, RG-188, and RG-316 groups with outer crimp sleeve sizing matched to their outer jacket diameters.
How is the center contact and outer shielding ferrule terminated?
The outer ferrule is crimped using standard BNC hex crimp tooling matched to RG-174 ferrule dimensions, while the center contact pin can be crimped or soldered depending on your field tooling setup.
Why buy a single factory-bagged connector kit rather than a multi-pack bulk lot?
Single-unit procurement lets you complete an exact bench repair or prototype build without paying for surplus surplus counts you will not consume. Shipping is $8 flat rate, free once the order passes $28, and orders leave the Idaho warehouse the same or next business day.
Nothing steadies an erratic bench trace faster than terminating a fresh BNC on clean coax. Strip the jacket, slide the ferrule, and lock in a clean signal.
