Texas Instruments SN74AS760N Non-Inverting Octal Buffer & Line Driver
Condition
Used equipment pull. Clean physical condition with intact pins and legible body markings. Evaluation: Visual inspection only. Function testing not performed.
Ships same or next business day from our Idaho warehouse. Honest pricing, no nonsense.
Online since 1999. Satisfaction guaranteed, every time.
Product Overview
Texas Instruments SN74AS760N is an Advanced Schottky TTL octal buffer and line driver designed with open-collector outputs in a standard 20-pin dual inline package (DIP-20). It features dual 4-bit non-inverting driver channels suitable for memory address driving, clock distribution, and bus-oriented signal transmission across legacy logic assemblies.
Key Features
- Octal buffer and line driver configuration (two 4-bit elements)
- Non-inverting logic outputs
- Open-collector output architecture
- Standard 4.5V to 5.5V TTL operating supply voltage
- Up to 64 mA output sink current capability
- Through-hole 20-pin plastic DIP (N suffix) package with 300-mil row spacing
Applications
- Bench repairs and component-level restoration of vintage digital boards
- Bus interfacing and open-collector level pulling in DIY TTL computing projects
- Industrial controller logic board maintenance and legacy system upkeep
Frequently Asked Questions
What is the logic configuration of the SN74AS760N?
The SN74AS760N features non-inverting open-collector outputs configured as two separate 4-bit sections, each enabled by an active-low output-enable input.
Are external pull-up resistors required for operation?
Yes. Because the outputs are open-collector, external pull-up resistors tied to the desired positive supply rail are necessary to establish high logic levels.
Why buy a single piece here instead of chasing a bulk surplus lot?
You get the exact photographed IC you need for a repair without buying surplus tubes of parts you will never use. Shipping is an $8 flat rate, free once your order passes $28, and orders leave our Idaho warehouse the same or next business day.
Open-collector drive from the classic Advanced Schottky line - right where a vintage bus needs a clean, dependable rebuild.
