8x8 Red LED Dot Matrix Display Module 3mm Dots Row Anode 16-Pin
Condition
New. Evaluation: Visual inspection only. Function testing not performed. Single 8x8 LED matrix display module included as pictured. Edge marking stamped 1088AS.
Same or next business day shipping from our Idaho warehouse. Reliable parts since 1999. Honest pricing, no nonsense.
We are here for our customers, with a no-hassle satisfaction guarantee.
Product Overview
Red 8x8 LED dot matrix display module featuring 64 individual 3 mm diffused round dots across a black contrast faceplate. Configured in a row anode, column cathode matrix arrangement for direct multiplexing or driving through serial matrix driver chips. Measures 32 mm square with two rows of 8 through-hole pins on 2.54 mm center spacing for breadboard or prototype PCB installation.
Key Features
- Matrix format: 8x8 grid (64 circular red LED dots)
- Dot diameter: 3 mm diffused white lenses with black face background
- Circuit configuration: Row Anode / Column Cathode
- Nominal dimensions: 32 mm x 32 mm square body
- Terminal layout: 16 straight through-hole pins in dual 8-pin rows
- Pin pitch: Standard 2.54 mm (0.1 in) spacing
- Forward voltage: Nominal 2.1 V per LED element
- Continuous forward current: 20 mA per segment
