Product Overview
Amphenol MS27468T15F35S MIL-DTL-38999 Series I 37-Socket Jam Nut Receptacle
Condition
New old stock. Unused condition with clean electroless nickel plating, undamaged mounting threads, and pliable blue O-ring seals. Markings legible: connector marked JMS27468T15F35S; contact package marked AMPHENOL AEROSPACE, 10-597872-451, M39029/56-348, MS27655-22D. Includes jam nut, lock washer, panel O-ring, protective cap, and package of crimp socket contacts. Sold each.
Ships same or next business day from our Idaho warehouse. Honest pricing, no nonsense.
Online since 1999. We are here for our customers, with a no-hassle satisfaction guarantee.
Product Overview
Built to MIL-DTL-38999 Series I standards, the Amphenol Aerospace MS27468T15F35S is a high-density, jam-nut mounting circular receptacle designed for harsh aerospace, defense, and industrial instrumentation environments. Operating as part of the Amphenol LJT series, this connector features an electroless nickel-plated aluminum shell with a quick-mating bayonet coupling mechanism and an environmental O-ring seal. The 15-35 insert arrangement provides 37 size 22D socket contact positions, supplied with matching military-specification crimp socket contacts for dependable signal transmission.
Key Features
- MIL-DTL-38999 Series I specification (Amphenol LJT series)
- Shell size 15 with 15-35 high-density insert arrangement (37 socket positions)
- Supplied with M39029/56-348 (Amphenol 10-597872-451 / MS27655-22D) size 22D crimp socket contacts
- Class F electroless nickel conductive finish over aluminum alloy shell
- Jam nut bulkhead mounting with included lock washer and panel sealing O-ring
- Three-point bayonet lock coupling mechanism for rapid, secure mating
- Operating temperature range from -65°C to +200°C
Applications
- Wiring avionics bays, flight control instrumentation, or cockpit telemetry harnesses requiring MIL-DTL-38999 Series I interconnects.
- Building custom test-bench breakout boxes and automated test equipment panels using bayonet-lock bulkhead feedthroughs.
- Upgrading motorsport wiring looms and heavy machinery data links requiring vibration-resistant, environmentally sealed connections.
- Outfitting custom robotics or electronics enclosures where a rugged, multi-pin panel-mount disconnect is needed.
Frequently Asked Questions
Are the crimp contacts included with this receptacle?
Yes. A package containing the matching size 22D crimp socket contacts (M39029/56-348 / Amphenol 10-597872-451) is included with each receptacle.
What wire gauge do the included contacts accept?
The included M39029/56-348 size 22D socket contacts accommodate 22 AWG to 28 AWG wire.
What mating connector does this receptacle pair with?
This shell size 15 jam nut receptacle mates with any standard MIL-DTL-38999 Series I (Amphenol LJT) size 15 plug configured with a 15-35 pin contact arrangement. The price per piece steps down with quantity, and the price-break table on this page shows each step.
Thirty-seven pins packed into a nickel-plated shell built to shrug off twenty Gs of vibration and keep talking. Thread the jam nut tight, crimp your harness, and lock it down.
