Panasonic ECH-U1H332JB5 - .0033uF 50V ECH-U SMD Film Capacitor
Condition
New. The photo shows a representative unit from our stock. Same or next business day shipping from our Idaho warehouse. Honest pricing, no nonsense. Online since 1999. We are here for our customers, with a no-hassle satisfaction guarantee.
Product Overview
Panasonic's ECH-U is a stacked metallized PPS film chip capacitor series, and this listing is its 3300 pF rung. In this part number 1H is the 50 V DC rating, 332 is the EIA picofarad code for 3300 pF, the .0033uF printed in the name, and J is the plus or minus 5 percent tolerance code; the trailing B5 matches no published Panasonic decode table, so the part number is quoted as it stands and no meaning is invented for it. The photo of this stock is the closest crop we have of the tape: a clear carrier strip crossing the frame with pockets running out past both edges, sprocket holes along the top, and the cover tape down and catching a highlight across the middle. Each pocket holds one upright slate gray body with a lighter rim and a round dimple in the top face, and no printed capacitance or part marking is visible on any of them in this photo. Ten pieces on the shelf, sold each.
Key Features
- Capacitance: .0033uF (3300 pF), EIA code 332 per Panasonic's published ECH-U decoding
- Capacitance tolerance: plus or minus 5 percent, the J code in Panasonic's published ECH-U tolerance table, where G is the plus or minus 2 percent code
- Rated voltage: 50 V DC, the 1H code per Panasonic's published ECH-U data
- Dielectric: stacked metallized PPS film, mold-less construction, per Panasonic's published ECH-U (ECHU(X)) series data
- Category temperature range: minus 55 to plus 125 degrees C, per Panasonic's published ECH-U series data
- Dissipation factor: tan d 0.6 percent or less at 20 degrees C and 1 kHz, per Panasonic's published ECH-U series data
- Insulation resistance: 3000 megohms or more, measured at 20 degrees C, 50 V, 60 seconds, per Panasonic's published ECH-U series data
- Withstand voltage between terminals: rated voltage times 150 percent for 60 seconds, per Panasonic's published ECH-U series data
- Mounting: surface-mount chip; Panasonic publishes reflow at 260 degrees C maximum, 95 seconds maximum above 220 degrees C, and lists the series RoHS compliant with no safety function
- Series: Panasonic ECH-U; no Panasonic table we can cite decodes the trailing B5, so we assign it no meaning
- Stock on hand: ten pieces, sold each
- Verify against Panasonic's published ECH-U series data before designing in.
