Product Overview
SPG SRA02CE Speed Controller with DIN Socket - Used
The SPG SRA02CE is a single-phase speed controller for 100 V, 60 Hz motors, supporting up to 2.2 A current. This unit includes its 11-pin DIN rail socket for simple installation and replacement.
SPG designed this controller to balance compact size with reliable performance. With built-in and remote control options, it adapts easily to automation and industrial equipment where precise speed adjustment is required.
Product Condition
Used, clean, and in good condition. Includes DIN rail-compatible socket base connector. Inspected and ready for continued use.
Product Overview
The SRA02CE allows adjustable motor speed through a front-mounted variable resistor, with the option to connect an external speed setter for remote operation. It offers smooth acceleration and deceleration, plus an electric brake for controlled stops. Rated IP2X, it provides protection against accidental finger contact with live parts, intended for dry, indoor environments.
Key Features
- Brand: SPG
- Model: SRA02CE
- Type: Single-phase motor speed controller
- Rated Voltage: 100 V AC
- Frequency: 60 Hz
- Max Current: 2.2 A
- Speed Range: 90–1700 rpm (60 Hz)
- Control: Front variable resistor or external speed setter
- Functions: Smooth start/stop, electric braking
- Socket: 11-pin DIN rail compatible base included
- Enclosure: IP2X rated
- Certification: CE marked
Applications
- Variable speed control of small induction motors
- Automation and conveyor systems
- Fan and pump speed regulation
- Light industrial machinery
- Retrofit into existing motor control panels
- Replacement for failed or outdated controllers
Frequently Asked Questions
What condition is the controller in?
It is used, clean, and in good condition. Includes its DIN rail-compatible socket base.
What motors can it control?
The SRA02CE supports small single-phase 100 V induction and reversible motors up to 2.2 A load.
How is motor speed adjusted?
Speed can be set using the front variable resistor or remotely via an external speed setter.
Does it support controlled stopping?
Yes, it offers smooth start/stop functions and an electric brake for quick, safe halts.
Where can this unit be installed?
It is IP2X rated, designed for dry indoor environments where accidental finger contact protection is required but no water ingress protection is needed.
Compact, adaptable, and engineered for reliable control, the SPG SRA02CE carries its precision into the next installation—its story continues with you.
