Samtec FleXYZ 10-Pin 2.00mm Pitch Board Stacking Female Header
Condition
New old stock. Unused surplus component in clean condition with straight gold-plated pins and intact lower alignment spacer.
Same or next business day shipping from our Idaho warehouse. Reliable parts since 1999. Honest pricing, no nonsense.
We are here for our customers, with a no-hassle satisfaction guarantee.
Product Overview
Samtec FleXYZ ESQT series part number ESQT-105-02-G-D-800 is a 10-contact elevated board-to-board female socket strip designed for mezzanine interconnects. Built on a 2.00 mm (0.0787 in) dual-row grid, it provides a fixed 0.800 in (20.32 mm) elevated body stack height with a secondary tail spacer to maintain pin alignment during through-hole assembly. Contacts feature gold plating for dependable mating integrity with standard 2.00 mm pin headers.
Key Features
- Total positions: 10 (2 rows of 5 pins)
- Pitch: 2.00 mm (0.0787 in) centerline spacing
- Elevated body stack height: 0.800 in (20.32 mm)
- Contact plating: Gold plating on contact area with gold flash on tails
- Lead style: -02 through-hole termination with bottom alignment spacer
- Insulator material: Black liquid crystal polymer
- Operating temperature range: -55°C to +125°C
Applications
- Mezzanine board-to-board interconnects requiring an extended 0.800-inch separation between parallel PCBs.
- Hardware prototyping and breadboarding where riser headers must clear tall inductors or electrolytic capacitors.
- Custom microcontroller carrier boards and sensor breakout stacking.
Frequently Asked Questions
What header pitch does this socket strip mate with?
This receptacle mates with standard 2.00 mm (0.0787 in) dual-row male pin headers.
Is the lower alignment bar removable or permanent?
The lower black alignment spacer holds the long through-hole tails at the proper 2.00 mm grid spacing for board insertion and sits directly above the solder tails.
Can I buy just the number of socket strips I need for my build?
Yes. Order the exact count your project calls for without being forced into buying a full reel or bulk factory lot. More pieces cost less each, and the price-break table on this page shows what each quantity costs. Orders ship for an $8 flat rate, ship free once the order passes $28, and leave our Idaho warehouse the same or next business day.
Tall board interconnects are what let complex stacks breathe instead of crowding each other out. Plug it into your layout, solder it down, and build upward.
